Programming Projects: DIIS convergence acceleration in SCF


Overview


Often, the convergence of the SCF procedure outlined in the previous projects is disappointingly slow. Fortunately, many convergence acceleration procedures have been developed, and, in this tutorial, you will implement one of the most popular: the direct inversion of the iterative subspace (DIIS). This tutorial is based upon the DIIS procedure described by Peter Pulay here.

This tutorial assumes you have already developed a working Hatree-Fock code, based on one of these tutorials.

The C++ code for the DIIS-accelerated SCF plugin can be found here. The C++ code and corresponding header for the DIIS manager class can be found here and here, respectively.


Procedure:


The basic idea of DIIS is simple. In the course of an SCF optimization, we have a series of approximate solution vectors (e.g. orbitals, densities, or Fock matrices). For each approximate solution vector, we can define an associated error vector. In DIIS, we choose an extrapolated solution vector as a linear combination of previous vectors, and the coefficients are chosen in a way that minimizes the error associated with the new vector.

Step 1. Develop a Hartree-Fock code

You must first develop your own Hartree-Fock SCF plugin to Psi4. You can base your plugin off of either of these tutorials. The notation used below is consistent with that used in those tutorials.

Step 2. Choose the Fock matrix as the current solution vector

Once we begin the SCF iterations, the parameter that we will extrapolate will be the Fock matrix (in the orthonormal basis):


The coefficients, ci, will be chosen such that the error associated with the extrapolated Fock matrix will tend to zero


We will also require that the coefficients sum to one



In general, this extrapolation should involve a small number of vectors, and you can store these matrices in main memory or on disk. The DIIS manager class given here stores eight solution and error vectors on disk.

Step 3. Choose an error vector

There are many possible definitions of the error vectors. For example, we could simply choose the change in the Fock matrix each iteration as an estimate of the error. Pulay proposed that the error vector should be given by the commutator of the Fock and density matrices (the orbital gradient) FiDiS-SDiFi, where Fi and Di are the Fock and density matrices at iteration i (in the AO or SO basis), and S is the overlap matrix. In the orthonormal basis defined by Löwdin's symmetric orthogonalization we have


As with the current solution vectors (the Fock matrices), we store a small number (eight) of error vectors. Again, you can store these in main memory or on disk.

Check your error vector from the first SCF iteration.

Step 4. Determining the coefficients, ci

Once you have accumulated at least two solution and error vectors, you can determine the coefficients, ci. The coefficients are chosen such that they minimize the norm of the extrapolated error vector


To find the coefficients, we use the method of Lagrange multipliers. We define the Lagrangian


where


are elements of the error matrix, and λ is the Lagrange multiplier for the constraint that the coefficients sum to one. The extra factor of two in the Lagrangian is introduced for convenience and has no effect on the optimal value of the coefficients, ci. We arrive at the following system of equations when we require that the Lagrangian be stationary with respect to variations in all of the coefficients and the Lagrange multiplier.




In your Psi4 plugin, you can solve this system of equations using the LAPACK routine DGESV. To do so, include the following header file:


  #include "psi4/libqt/qt.h"
You can then use the function C_DGESV. For the call structure for C_DGESV, see lapack_intfc.cc.

Note that the computational cost of the construction of the error matrix can be reduced by recognizing (i) the matrix is symmetric so only the lower or upper triangle need be computed and (ii) only one row/column must explicitly be computed each iteration. The remainder of the matrix can be stored (in memory or on disk) and reused iteration to iteration.

Check your coefficients from the first DIIS extrapolation.

Step 5. Extrapolate the Fock matrix

Once you have determined the coefficients, ci, extrapolate the Fock matrix according to



Now, we resume the Hatree-Fock procedure. Diagonalize the extrapolated Fock matrix to determine its eigenvectors (the molecular orbitals, C') and eigenvalues (the molecular orbital energies, ε)



As in the previous tutorials, back transform one index of C' to the original AO basis in order to build the density matrix for the next iteration:




Step 6. Replacing solution and error vectors


Since only a small number of solution and error vectors (e.g eight) are used in the extrapolation procedure, we will need to replace some of the older vectors as the SCF procedure goes beyond eight iterations. You can choose to replace either the oldest vectors or those vectors with the largest associated error vector. Our DIIS manager replaces the vector with the largest associated error.


Step 7. Monitoring convergence


In our previous tutorials, the SCF procedure was considered converged when changes in energy and density between iterations fell below some predefined thresholds. Here, we use the change in the energy and the the root-mean square (RMS) orbital gradient to measure convergence.

Consider the Hartree-Fock procedure for the same molecule/basis set combinations used in the previous tutorials. Without DIIS, the energy and orbital gradient should converge to 12 decimal places in about 28 iterations:


    Guess energy:     -118.308230720196

    ==>  Begin SCF Iterations <==

     Iter               energy                   dE          RMS |[F,P]|
        0     -73.196938802615      45.111291917580       0.161149650787
        1     -74.939192979935      -1.742254177320       0.012516596135
        2     -74.944687307745      -0.005494327810       0.002868867004
        3     -74.945047846381      -0.000360538636       0.000948342720
        4     -74.945095717316      -0.000047870934       0.000366501367
        5     -74.945103245253      -0.000007527938       0.000147962847
        6     -74.945104500848      -0.000001255594       0.000060823893
        7     -74.945104714602      -0.000000213755       0.000025151359
        8     -74.945104751242      -0.000000036639       0.000010420756
        9     -74.945104757536      -0.000000006294       0.000004320278
       10     -74.945104758618      -0.000000001082       0.000001791480
       11     -74.945104758804      -0.000000000186       0.000000742916
       12     -74.945104758836      -0.000000000032       0.000000308089
       13     -74.945104758842      -0.000000000006       0.000000127766
       14     -74.945104758842      -0.000000000001       0.000000052985
       15     -74.945104758843      -0.000000000000       0.000000021973
       16     -74.945104758843       0.000000000000       0.000000009112
       17     -74.945104758843       0.000000000000       0.000000003779
       18     -74.945104758843      -0.000000000000       0.000000001567
       19     -74.945104758843       0.000000000000       0.000000000650
       20     -74.945104758843       0.000000000000       0.000000000270
       21     -74.945104758843       0.000000000000       0.000000000112
       22     -74.945104758843       0.000000000000       0.000000000046
       23     -74.945104758843       0.000000000000       0.000000000019
       24     -74.945104758843       0.000000000000       0.000000000008
       25     -74.945104758843       0.000000000000       0.000000000003
       26     -74.945104758843      -0.000000000000       0.000000000001
       27     -74.945104758843       0.000000000000       0.000000000001

    SCF iterations converged!

    * SCF total energy:     -74.945104758843

For the same convergence thresholds, DIIS reduces the number of iterations to only nine:


    Guess energy:     -118.308230720196

    ==>  Begin SCF Iterations <==

     Iter               energy                   dE          RMS |[F,P]|
        0     -73.196938802615      45.111291917580       0.161149650787
        1     -74.939192979935      -1.742254177320       0.012516596135
        2     -74.944687307745      -0.005494327810       0.002868867004
        3     -74.945059469653      -0.000372161908       0.000830998716
        4     -74.945103419151      -0.000043949498       0.000142890940
        5     -74.945104756790      -0.000001337639       0.000006828537
        6     -74.945104758843      -0.000000002052       0.000000068811
        7     -74.945104758843      -0.000000000000       0.000000000398
        8     -74.945104758843       0.000000000000       0.000000000000

    SCF iterations converged!

    * SCF total energy:     -74.945104758843

If we double the O-H bond length


molecule {
O
H 1 R
H 1 R 2 A

R = 1.8
A = 104.5
# add this line!
symmetry c1
}

we find that the basic SCF procedure does not converge:


    Guess energy:     -116.837914524518

    ==>  Begin SCF Iterations <==

     Iter               energy                   dE          RMS |[F,P]|
        0     -73.226880190015      43.611034334503       0.037704098895
        1     -73.362990265269      -0.136110075254       0.068817042077
        2     -73.553585133343      -0.190594868074       0.076418280252
        3     -73.590354082648      -0.036768949305       0.082674491025
        4     -73.682157222699      -0.091803140051       0.082580895233
        5     -73.678727769308       0.003429453391       0.085365751694
        6     -73.735922659086      -0.057194889778       0.084107422060
        7     -73.717253914233       0.018668744853       0.086133433309
        8     -73.760261977557      -0.043008063324       0.084608450174
        9     -73.735037381968       0.025224595589       0.086406150756
       10     -73.771698133826      -0.036660751858       0.084803784715
       11     -73.743474775749       0.028223358077       0.086517537730
       12     -73.777171073830      -0.033696298081       0.084888261557
       13     -73.747532013052       0.029639060777       0.086566973068
       14     -73.779813873486      -0.032281860434       0.084926973128
       15     -73.749495788237       0.030318085249       0.086589937774
       16     -73.781095646346      -0.031599858109       0.084945260963
       17     -73.750449319650       0.030646326696       0.086600861938
       18     -73.781718642130      -0.031269322479       0.084954034686
       19     -73.750913034440       0.030805607690       0.086606120963
       20     -73.782021759446      -0.031108725006       0.084958276341
       21     -73.751138715146       0.030883044300       0.086608667749
       22     -73.782169315262      -0.031030600116       0.084960334716
       23     -73.751248589775       0.030920725488       0.086609904671
       24     -73.782241162329      -0.030992572554       0.084961335442
       25     -73.751302092769       0.030939069560       0.086610506272
       26     -73.782276149910      -0.030974057141       0.084961822407
       27     -73.751328148099       0.030948001811       0.086610799076
       28     -73.782293188914      -0.030965040815       0.084962059474
       29     -73.751340837277       0.030952351637       0.086610941634
       30     -73.782301487171      -0.030960649894       0.084962174909
       31     -73.751347017148       0.030954470023       0.086611011053
       32     -73.782305528605      -0.030958511458       0.084962231124
       33     -73.751350026892       0.030955501713       0.086611044860
       34     -73.782307496887      -0.030957469994       0.084962258500
       35     -73.751351492717       0.030956004170       0.086611061324
       36     -73.782308455493      -0.030956962776       0.084962271833
       37     -73.751352206614       0.030956248879       0.086611069342
       38     -73.782308922361      -0.030956715747       0.084962278327
       39     -73.751352554301       0.030956368059       0.086611073248
       40     -73.782309149738      -0.030956595437       0.084962281489
       41     -73.751352723635       0.030956426103       0.086611075149
       42     -73.782309260478      -0.030956536843       0.084962283029
       43     -73.751352806106       0.030956454372       0.086611076076
       44     -73.782309314411      -0.030956508306       0.084962283779
       45     -73.751352846271       0.030956468140       0.086611076527
       46     -73.782309340678      -0.030956494407       0.084962284145
       47     -73.751352865833       0.030956474845       0.086611076747
       48     -73.782309353471      -0.030956487638       0.084962284323
       49     -73.751352875360       0.030956478111       0.086611076854
       50     -73.782309359701      -0.030956484342       0.084962284409

Without DIIS, the SCF procedure appears to oscillate between two different solutions. On the other hand, SCF with DIIS converges nicely in only 15 iterations:


    Guess energy:     -116.837914524518

    ==>  Begin SCF Iterations <==

     Iter               energy                   dE          RMS |[F,P]|
        0     -73.226880190015      43.611034334503       0.037704098895
        1     -73.362990265269      -0.136110075254       0.068817042077
        2     -73.553585133343      -0.190594868074       0.076418280252
        3     -74.464883669436      -0.911298536093       0.032080900797
        4     -74.429023374665       0.035860294771       0.041606480071
        5     -74.456614357821      -0.027590983157       0.034310669154
        6     -74.511256860259      -0.054642502438       0.000395057332
        7     -74.511195829728       0.000061030531       0.001422608517
        8     -74.511030534112       0.000165295616       0.002554059031
        9     -74.511052613564      -0.000022079452       0.002456520204
       10     -74.511052329069       0.000000284495       0.002457817744
       11     -74.511322873032      -0.000270543963       0.000008732217
       12     -74.511322876759      -0.000000003727       0.000000074001
       13     -74.511322876760      -0.000000000000       0.000000000420
       14     -74.511322876760       0.000000000000       0.000000000001

    SCF iterations converged!

    * SCF total energy:     -74.511322876760

You can check your expansion coefficients, F' matrices, or error vectors for this case.

We should note here that there are other methods, such as level shifting, that can improve the convergence of SCF in divergent cases without the use of DIIS.
