Programming Projects: SCF with density fitting


In this project, you will learn how to write a restricted Hartree-Fock self-consistent field (SCF) solver as a plugin to the Psi4 electronic structure package. The solver will make use of density fitting technology so as to avoid the generation and storage of the four-index two-electron repulsion integral tensor. In addition to learning how an SCF procedure actually works, you will also learn how to interface with the Matrix class and some of the integral evaluation machinery in Psi4.

For a tutorial that does not require the use of Psi4, see Daniel Crawford's SCF project (this project was adapted from that one). That project does not use density fitting, and all required integrals are read from text files so that your code can be written independently of any electronic structure package.

For additional information about the SCF procedure, I recommend Szabo and Ostlund's awesome (and cheap!) book Modern Quantum Chemistry or David Sherrill's online notes.

The C++ code for this SCF plugin can be found here. If you are uncomfortable with BLAS, this version uses loops and might be easier to understand when following along with the notes.


Note: we use atomic units throughout this tutorial.

At the Hartree-Fock level of theory, the N-electron wave function is approximated as an antisymmetrized product of N one-electron functions called molecular orbitals (MOs). We call this type of wave function a Slater determinant, and the associated electronic energy can be expressed as

where D represents a density matrix (defined below), h represents the core Hamiltonian matrix, and F represents the Fock matrix. Here, Greek indices represent atomic orbital (AO) basis functions. The core Hamiltonian matrix contains integrals that represent the kinetic energy of an electron (T) and electron-nuclear potential energy (V):

The matrix elements of the kinetic energy are integrals over the real-valued AO basis functions, χ, with the quantum-mechanical kinetic energy operator:

We should note here that these basis functions are not orthogonal, and we define the overlap matrix , S, as

The matrix elements of the electron-nuclear potential energy are integrals over basis functions with the potential energy operator (Z/r):

Here, there are multiple nuclei, labeled A, with nuclear charge ZA and a distance from the electron of rA. The Fock matrix is defined as

where the symbol, (μν|λσ) represents a two-electron repulsion integral, defined as

The actual working equations for Hartree-Fock theory are derived by considering a constrained minimization of the electronic energy with respect to the shape of the molecular orbitals, φ, which are expanded as a linear combination of atomic orbitals:

Using Lagrange's method of undetermined multipliers, the electronic energy is minimized with respect to the elements of C subject to the constraint that the molecular orbitals form an orthonormal set. Eventually, these considerations lead to an eigenvalue problem; the molecular orbitals are the eigenvectors of the Fock matrix, and the corresponding eigenvalues (which are the multipliers) are interpreted as the molecular orbital energies.

We now develop a computational procedure for determining the molecular orbitals and the electronic energy with the Psi4 electronic structure package.


Step 1. Create a new plugin

Create a new plugin, as described here. If you called your plugin "myscf," then all of your code can be placed inside Open and locate the myscf(Options & options) function:

    extern "C"
    SharedWavefunction myscf(SharedWavefunction ref_wfn, Options& options)
        int print = options.get_int("PRINT");

        /* Your code goes here */

        // Typically you would build a new wavefunction and populate it with data
        return ref_wfn;

Like the comment says, your code goes there!

Before moving on, open the input file in your plugin directory (input.dat) and look at the molecule block

    molecule {
    H 1 R
    H 1 R 2 A

    R = .9
    A = 104.5
    # add this line!
    symmetry c1

This plugin will not make use of point group symmetry, so you should add a line specifying that the computation be performed using C1 symmetry. Now, add a flag indicating that the computation will use density fitting techniques:

set {
  #add this line!
  scf_type df
  basis sto-3g

For the remainder of this project, I've assumed that the rest of the input is unchanged. Keep this in mind when comparing to my results.

Step 2. Obtain 1-electron integrals

Now, close input.dat and open In order to use Psi4's built-in integral libraries, matrix classes, etc., we must include the corresponding headers at the top of the file. Add the following headers:

#include "psi4/libmints/wavefunction.h"
#include "psi4/libmints/mintshelper.h"
#include "psi4/libmints/matrix.h"
#include "psi4/libmints/vector.h"
#include "psi4/libmints/basisset.h"
#include "psi4/libmints/molecule.h"
#include "psi4/lib3index/dftensor.h"
#include "psi4/libqt/qt.h"

We can now use Psi4's MintsHelper class to grab all of the one-electron integrals we'll need inside the function SharedWavefunction myscf(SharedWavefunction ref_wfn, Options& options).

    // grab the one-electron integrals from MintsHelper:
    std::shared_ptr<MintsHelper> mints (new MintsHelper(ref_wfn));

    // one-electron kinetic energy integrals
    std::shared_ptr<Matrix> T = mints->so_kinetic();

    // one-electron potential energy integrals
    std::shared_ptr<Matrix> V = mints->so_potential();

    // overlap integrals
    std::shared_ptr<Matrix> S = mints->so_overlap();

    // build the core hamiltonian
    std::shared_ptr<Matrix> h = (std::shared_ptr<Matrix>)(new Matrix(T));

Note that all of the MintsHelper functions we call all have the prefix "so," which stands for "symmetry orbital." The SO basis is obtained by transforming the AO basis functions so that the SOs belong to a proper irreducible representation in the molecule's point group. If we are not using symmetry (which is the case here), then the AO and SO bases are equivalent.

Step 3. Obtain 2-electron integrals

Now, we need the two-electron integrals in the SO basis. This is a complicated task, so we're going to cheat and use density-fitted three-index integrals instead of the full four-index electron repulsion integral tensor. In order to construct the three-index integrals, we will need (1) the molecule object, (2) the primary basis set, and (3) the auxiliary (or density-fitting) basis set. To generate the three-index integrals:

    // grab the molecule from the wavefunction that was passed into the plugin
    std::shared_ptr<Molecule> mol = ref_wfn->molecule();

    // get primary basis:
    std::shared_ptr<BasisSet> primary = ref_wfn->get_basisset("ORBITAL");

    // total number of basis functions
    int nso = primary->nbf();

    // get auxiliary basis:
    std::shared_ptr<BasisSet> auxiliary = ref_wfn->get_basisset("DF_BASIS_SCF");

    // total number of auxiliary basis functions
    int nQ = auxiliary->nbf();

Note that we are using the strings "ORBITAL" and "DF_BASIS_SCF" when we grab the primary and auxiliary basis sets. What are these?

The primary basis set ("ORBITAL") should be set in the input file (e.g. "set basis sto-3g"). It was automatically set to STO-3G when you generated your plugin (check if you don't believe me!). The auxiliary basis set ("DF_BASIS_SCF") can be specified in the input file, but it was not automatically set when the plugin was created. Fortunately, since we requested that the scf_type be "DF", Psi4 is smart enough to pick a DF basis for you. If no "DF_BASIS_SCF" was specified in the input, then Psi4 picks the "JKFIT" variant of the primary "ORBITAL" basis that it deems appropriate. For the STO-3G basis, Psi4 will choose smallest possible "JKFIT" set, def2-svp-jkfit.

Moving on!

    // use the molecule to determine the total number of electrons
    int charge     = mol->molecular_charge();
    int nelectron  = 0;
    for (int i = 0; i < mol->natom(); i++) {
        nelectron += (int)mol->Z(i);
    nelectron -= charge;

    // this code only works for closed shells
    if ( nelectron % 2 != 0 ) {
        throw PsiException("plugin myscf only works for closed shells",__FILE__,__LINE__);

    // the number of doubly occupied orbitals (or alpha electrons)
    int na = nelectron / 2;

    // allocate memory for SO->MO coefficients
    std::shared_ptr<Matrix> Ca = (std::shared_ptr<Matrix>)(new Matrix(nso,nso));

    // construct the three-index integrals
    // since we want the SO-basis integrals, it is fine to pass empty Ca matrix
    // similarly, the number of active vs inactive orbitals isn't really important here.
    std::shared_ptr<DFTensor> DF (new DFTensor(primary,auxiliary,Ca,na,nso-na,na,nso-na,options));
    std::shared_ptr<Matrix> Qso = DF->Qso();

Now, we have a Matrix object, Qso, that contains the three-index integrals. The Psi4 Matrix class has a number of built in functions [add(), zero(), diagonalize(), print(), etc.]. We already used the add() function above to build the core Hamililtonian. The Matrix class also allows the user to access the data directly:

    double ** Qp = Qso->pointer();

The double pointer Qp points to the three-index integrals, and a single element (Q|μν) is accessed as Qp[Q][mu*nso+nu]. Here, Q is the auxiliary basis function index, μ and ν are primary basis function indices, and nso is the number of primary basis functions. The four-index integrals could be constructed as a contraction of the three-index integrals:

but doing so defeats the purpose of using three-index integrals. First, the cost of that step would scale computationally with the fifth power of the system size, whereas the SCF procedure should only scale as the fourth-power. Second, the four-index tensor is a larger object; it takes up much more space than the three-index integrals either in memory or on disk. We will avoid building the four-index integrals by expressing the Fock matrix in terms of the three-index integrals (see Step 6 below).

Step 4. Symmetric orthogonalization

Oftentimes in electronic structure theory, we would prefer to work within a basis of orthonormal functions, which simplifies the math. However, our SO basis functions are not orthogonal. We can generate an orthogonal basis via Löwdin's symmetric orthogonalization. One first finds a transformation that diagonalizes the overlap matrix, S,

where s is a diagonal matrix of eigenvalues. We then construct the symmetric orthogonalization matrix by taking the inverse square root of the eigenvalues and backtransforming them to the original basis.

The following code snippet illustrates how to diagonalize the overlap matrix using Psi4's Matrix class. The back transformation is performed using a built-in function in the Matrix class.

    // allocate memory for eigenvectors and eigenvalues of the overlap matrix
    std::shared_ptr<Matrix> Sevec ( new Matrix(nso,nso) );
    std::shared_ptr<Vector> Seval ( new Vector(nso) );

    // build S^(-1/2) symmetric orthogonalization matrix

    std::shared_ptr<Matrix> Shalf = (std::shared_ptr<Matrix>)( new Matrix(nso,nso) );
    for (int mu = 0; mu < nso; mu++) {
        Shalf->pointer()[mu][mu] = 1.0 / sqrt(Seval->pointer()[mu]);

    // transform Seval back to nonorthogonal basis

Check your S-1/2 matrix using the Shalf->print() function.

Step 5. Guess orbitals, density, and energy

To obtain a set of guess orbitals and an initial density, we approximate the initial Fock matrix as the core Hamiltonian

Next, use the symmetric orthogonalization matrix to bring this Fock matrix to a basis of orthonormal functions

Check your F' matrix.

We will now diagonalize this transformed Fock matrix to determine its eigenvectors (the molecular orbitals, C') and eigenvalues (the molecular orbital energies, ε)

The matrix C' represents the molecular orbitals as a linear combination of orthonormalized basis functions, but what we really want is the linear combination of nonorthogonal AO (or SO) basis functions. We need to back transform one index of C' to the original AO basis

Since you are only transforming one index, don't use the Matrix class back_transform() call. You could use the Matrix class gemm() call

        // Find C = S^(-1/2)C'

where Fevec is a Matrix containing the eigenvectors of F'. Alternatively, you could grab the appropriate pointers

        double ** cp = Ca->pointer();
        double ** sp = Shalf->pointer();
        double ** fp = Fprime->pointer();

and transform that index using explicit loops. Check your MO coefficients.

Now, we define the density matrix as the contraction of the molecular orbital coefficients over the N/2 lowest-energy molecular orbitals (the doubly occupied orbitals):

This density can then be used to evaluate the initial electronic energy and to obtain a new Fock matrix.

Check your density.

Step 6. The SCF procedure

You may have noticed that the Fock matrix depends on the density:

and the density is determined by diagonalizing the Fock matrix. If this seems a bit circular, you're right; we must determine the density for the system self-consistently. We repeatedly construct and diagonalize the Fock matrix until the electronic energy and density matrix cease to change. The self-consistent nature of the solution is the source of the name of the procedure: the Hartree-Fock self-consistent field procedure.

The SCF procedure is quite simple. Repeat Step 5, but use the correct Fock matrix (rather than the core Hamiltonian), until the changes in the energy and the density between iterations fall below some threshold.

Since we're using three-index integrals instead of four-index integrals, we rewrite the Fock matrix as

Programming this expression is a little more manageable if we write the Fock matrix in terms of the coulomb and exchange matrices, J and K



The coulomb matrix can be built at third-power computational cost as

where we have introduced the intermediate quantity

The exchange matrix can be built at fourth-power computational costs as

where we have introduced another intermediate tensor, defined as

Check your coulomb, exchange, and Fock matrices from the first SCF iteration.

Step 7. Monitoring convergence

The SCF procedure is considered converged when the changes in the energy and density between iterations fall below some predefined thresholds. In Psi4, these convergence thresholds can be specified in the input file and obtained in your plugin from the "options" object:

    // grab some input options
    double e_convergence = options.get_double("E_CONVERGENCE");
    double d_convergence = options.get_double("D_CONVERGENCE");

During the SCF procedure, we must monitor the change in the energy between iterations k-1 and k

as well as the change in the density

For the present molecule/basis set, the energy and density should converge to 8 decimal places in about 20 iterations:

    Guess energy:     -118.308230720196

    ==>  Begin SCF Iterations <==

     Iter               energy                   dE                   dD
        0     -73.196938802615      45.111291917580       1.897398367073
        1     -74.939192979935       1.742254177320       0.112061053539
        2     -74.944687307745       0.005494327810       0.028486807507
        3     -74.945047846381       0.000360538636       0.010519702816
        4     -74.945095717316       0.000047870934       0.004071261334
        5     -74.945103245253       0.000007527938       0.001631352920
        6     -74.945104500848       0.000001255594       0.000664268555
        7     -74.945104714603       0.000000213755       0.000272761967
        8     -74.945104751242       0.000000036639       0.000112497614
        9     -74.945104757536       0.000000006294       0.000046510048
       10     -74.945104758618       0.000000001082       0.000019254367
       11     -74.945104758804       0.000000000186       0.000007976956
       12     -74.945104758836       0.000000000032       0.000003306204
       13     -74.945104758842       0.000000000006       0.000001370652
       14     -74.945104758843       0.000000000001       0.000000568310
       15     -74.945104758843       0.000000000000       0.000000235655
       16     -74.945104758843       0.000000000000       0.000000097721
       17     -74.945104758843       0.000000000000       0.000000040524
       18     -74.945104758843       0.000000000000       0.000000016805
       19     -74.945104758843       0.000000000000       0.000000006969

    SCF iterations converged!

    * SCF total energy:     -74.945104758843

Note that the energy here is the total energy

You can grab the nuclear repulsion energy from the molecule object:

    double e_nuc = mol->nuclear_repulsion_energy();
